15001V3.1 · INVENTORY REVISION 1
Newsstand
piece by piece.
590Counted units
595Advertised pieces
152Part shapes
273Color & print variants
Counting policy & reconciliation · 423 source callouts
Instruction callout units; minifigure components excluded. Supplied lighting assemblies counted as supplied units; each four-flower sprue counts as one. Packaging previews and repeated assemblies are not added again.
| Measure / rule | Value | Explanation |
|---|---|---|
| Count reconciliation and interpretation | — | — |
| Count measure | Units | Basis |
| Advertised set size | 595 | PDF cover, page 1: 595PCS. The cover does not define its counting convention. |
| Parts-rectangle quantities | 590 | Sum of every included xN callout, before shape grouping. |
| Inventory quantity | 590 | Shape/color/print quantities calculated from the occurrence ledger. |
| Inventory minus occurrence ledger | 0 | Must equal zero: grouping must preserve the source quantity. |
| Advertised target minus counted inventory | 5 | Unresolved under the agreed scope. No filler or guessed part rows were added. |
| Supplied lighting assemblies included | 7 | 1 lamp assembly, 1 distributor, 1 battery box, 2 extension cables, 1 light bar and 1 wired round fitting. |
| Four-flower sprues included | 3 | Three x1 callouts: one red, one white, one yellow. Each is one supplied sprue containing four flower heads. |
| Other included callout units | 580 | Counted units less lighting assemblies and flower sprues. |
| Illustrated part callouts | 423 | 423 quantity-bearing individual part references. |
| Parts rectangles | 143 | 143 source rectangles across 102 PDF build pages. |
| Shape IDs | 152 | One arbitrary ID per interpreted shape, reused across colors and prints. |
| Color / print inventory rows | 273 | Separate quantity rows for every observed shape and color/print combination. |
| Rule / limitation | — | How it was applied |
| Minifigure components | — | Excluded. The figure on PDF page 31 is outside this inventory. Its component count was not inferred from the exploded assembly drawing. |
| Five-piece difference | — | The included parts rectangles total 590. The booklet provides no confirmed five-piece adjustment under the requested exclusions and assembly conventions. This workbook does not claim a match to 595. |
| Printed variants | — | Print IDs print-000001 through print-000021 act as colors. The underlying shape ID is shared with plain-color pieces of that shape. |
| Rotation and handedness | — | Compare stud layout, face fittings, contours and underside features. Inverted brackets and outward/inverted blue curves remain separate shapes. No size estimate uses raster-image scale. |
| Turntable faces | — | The recessed face on PDF page 36 is provisionally grouped with the raised-center turntable plate on pages 44 and 151 as opposite faces. Confidence is Medium. |
| Lighting | — | Each supplied wired assembly is counted once at its build-step callout. The introductory package lists repeat across languages and are not counted again. |
| Flower counting | — | The printed x1 values refer to four-flower sprues. Counting detached heads instead would add 9 units, producing 599; that alternate convention is not mixed into the main tally. |
| F-pack contents preview | — | The six special-brick units shown on PDF page 31 are counted at their later build callouts, not again at the bag preview. |
| Assembly-only steps | — | 14, 23, 30, 38, 46, 52, 65, 68, 76, 81, 90, 92, 99, 102, 113, 118, 135, 140, 147, 154, 157, 160, 166 and 167 have no added parts rectangle. |
| Confidence: High | — | Quantity is verified and the shape is distinguishable by visible studs and geometry. Color names are visual descriptions, not manufacturer color codes. |
| Confidence: Medium | — | Quantity is verified. Exact mold dimensions, underside interpretation, custom/special geometry or a grouping decision needs physical confirmation; see the row notes. |
| Source indexing | — | PDF page numbers are one-based. The printed booklet page is PDF page minus 30 throughout the included build section. Item numbers read the rectangle from left to right, and top to bottom where needed. |
| Quantity cross-check | Result | Coverage |
| Visual quantity review | Complete | All 423 callouts were visually transcribed. |
| OCR quantity cross-check | 422 of 423 | All quantities agree where OCR read the label. Page 103, step 91, has one additional x1 label verified visually. |
| Parts-box coverage | Complete | All build pages were reviewed, including the 24 assembly-only steps listed above. |
THE PARTS LIST
